DN Optic 1.25G 20km SFP transceiver

DN Optic 1.25Gbps SFP Optical Transceiver, 20km Reach GP L2x(D) Features Dual data-rate of 1.25Gbps/1.063Gbps operation 1310nm FP laser and PIN photodetector for 20km transmission Compliant with SFP MSA and SFF-8472 with duplex LC receptacle Digital Diagnostic Monitoring: Internal Calibration or External Calibration Compatible with SONET OC-24-LR-1 Compatible with RoHS +3.3V single power supply Operating case temperature: Standard : 0 to +70 C Industrial : -40 to +85 C Applications Gigabit Ethernet Fiber Channel Switch to Switch interface Switched backplane applications Router/Server interface Other optical transmission systems Description The SFP transceivers are high performance, cost effective modules supporting dual data-rate of 1.25Gbps/1.0625Gbps and 20km transmission distance with SMF. The transceiver consists of three sections: a FP laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements.
