Key Features • Adopt the new Vstar GUI, easy to operate and run smoothly • Support intelligent coding VSMart, greatly reducing storage space • Improved compatibility for HDD. Support max. of 10TB • Support Intelligent Detection and Human Detection * 01 Year Official Warranty Read more
You can buy the Jovision JVS ND6616 HD 16 Channel H.265 1 SATA NVR from us at the best price. You can either buy it through our website or directly visit our office.
| Specifications | Descriptions |
|---|---|
| Model | JVS-ND6616-HD |
| Video & Audio | |
| IP Camera Input | 16 Channel |
| Audio Input/ Output | 1 Channel RCA Output,16 Channel Audio output through HDMI |
| Display | |
| Interface | 1 RJ45 Port (10/100Mbps) |
| Resolution | 16CH 5.0MP/ 4.0MP/ 1080p/ 960p/ 720p |
| Max Decoding | 16CH 5.0MP/ 4.0MP/ 1080p/ 960p/ 720p @25fps |
| Multi-Screen Display | 4/ 5/ 6/ 7/ 8/ 9/ 10/ 11/ 12/ 13/ 14/ 15/ 16 |
| OSD | Camera Name & Time, Recording, Alarm Detecting, Remote connection, Thank you for reading this post, don't forget to subscribe! Volume, Channel Number |
| Recording | |
| Compression | H.265/H.264 |
| Record Mode | Manual, Schedule, MD |
| Video Detection & Alarm | |
| Trigger Events | Recording, Snapshot, PTZ, Voice, E-mail, Client, Buzzer |
| Video Detection | Motion Detection, No Video Detection |
| Playback & Backup | |
| Sync Playback | 1CH 5.0MP, 1CH 4.0MP, 1CH 3.0MP, 2CH 1080p |
| Model JVS-ND6616-HD Video & Audio IP Camera Input 16 Channel Audio Input/ Output 1 Channel RCA Output,16 Channel Audio output through HDMI Display Interface 1 HDMI, 1 VGA Resolution HDMI: 2560×1440, 1920×1080, 1440×900, 1280×1024, 1280×720, 1024×768 VGA: 1920×1080, 1440×900, 1280×1024, 1280×720, 1024×768 Max Decoding 16CH 5.0MP/ 4.0MP/ 1080p/ 960p/ 720p @25fps Multi-Screen Display 4/ 5/ 6/ 7/ 8/ 9/ 10/ 11/ 12/ 13/ 14/ 15/ 16 OSD Camera Name & Time, Recording, Alarm Detecting, Remote connection, Thank you for reading this post, don't forget to subscribe! Volume, Channel Number Recording Compression H.265/H.264 Resolution 16CH 5.0MP/ 4.0MP/ 1080p/ 960p/ 720p Record Mode Manual, Schedule, MD Video Detection & Alarm Trigger Events Recording, Snapshot, PTZ, Voice, E-mail, Client, Buzzer Video Detection Motion Detection, No Video Detection Playback & Backup Sync Playback 1CH 5.0MP, 1CH 4.0MP, 1CH 3.0MP, 2CH 1080p Search Mode | Channel Number / Recording Type / Dat |
| Playback Function | Day View, Hour View, Back Step, Rewind, Pause, Play, Fast Forward, Slow, Step, Full Screen, Snap, Sound On/Off, Zoom |
| Backup Mode | FAT32 USB Device/ Network |
| Network & Interfaces | |
| Network Function | TCP/IP, DHCP, UDP, SMTP, NTP, CloudSEE |
| Smart Phone | Support iOS, Android App |
| Interoperability | ONVIF 2.4 |
| Storage | |
| SATA | 1 SATA Interfaces |
| Capacity | Up to 10TB |
| USB | 2x USB |
| General | |
| Power Supply | DC 12V |
| Consumption | ≤10W (Without HDD) |
| Working Temperature | -10°C ~ 55°C |
| Working Humidity | 10% ~ 90% |
| Dimensions | 260x48x227mm |
| Weight | ≤1.0kg (Without HDD) |
