Key Features MPN: DH-XVR1B16-I Model: XVR1B16-I H.265+/H.265 dual-stream video compression Supports Full-channel AI-Coding Supports HDCVI/AHD/TVI/CVBS/IP video inputs Max 18 channels IP camera inputs Read more
The Dahua XVR1B16-I is a stand-alone recorder that captures HDMI videos as you watch them, without the need for a PC. Be it your games or sports games, Dahua DH-XVR1B16-I records HDMI video at the press of a button or on a schedule, even when your TV is powered off. With the remote control, view the recorded videos at your leisure. The snapshot function lets you capture your favorite moments into inspiring, high-quality pictures. The Dahua DH-XVR1B16-I makes post-production easy as well. The built-in video editor allows you to trim and merge clips seamlessly without a PC. Knowing you'll have the final touch just makes recording so much easier. The Dahua XVR1B16-I comes with a 1-year warranty.
| Specifications | Descriptions |
|---|---|
| System | |
| Main Processor | Embedded processor |
| Operating System | Embedded linux |
| Audio and Video | |
| IP Camera Input | 16+2 channels, each channel up to 6MP |
| Two-Way Talk | Reuse audio in/out, RCA |
| Display | |
| Interface | 1 HDMI; 1 VGA |
| Resolution | 1080N; 720p; 960H; D1; HD1; BCIF; CIF; QCIF |
| Multi-Screen Display | When IP extension mode not enabled: 1/4/8/9/16 When IP extension mode enabled: 1/4/8/9/16 |
| OSD | Camera title; Time; Video loss; Camera lock; Motion detection; Recording |
| Recording | |
| Compression | AI Coding/H.265+/H.265/H.264+/H.264 |
| Record Rate | Main Stream: the 1st channel 1080N/720p (1 fps–25/30 fps), others 1080N/720p (1 fps–15 fps); 960H/D1/HD1/BCIF/CIF/QCIF (1 fps–25/30 fps) Sub stream: CIF/QCIF (1 fps–7 fps) |
| Bit Rate | 32 kbps–4096 kbps per channel |
| Record Mode | Manual; Schedule (General, Continuous); MD (Video detection: Motion Detection, Video Loss, Tampering); Alarm; Stop |
| Record Interval | 1 min–60 min (default: 60 min), Pre-record: 1 sec–30 sec, Post-record: 10 sec–300 sec |
| Video Detection And Alarm | |
| Trigger Event | Recording; PTZ; Tour; Video Push; Email; FTP; Snapshot; Buzzer and Screen Tips |
| Video Detection | Motion Detection, MD Zones: 396 (22 × 18), Video Loss, Tampering and Diagnosis |
| Alarm Input | N/A |
| Relay Output | N/A |
| Playback And Backup | |
| Sync Playback | 1/4/9/16 |
| Search Mode | Time/Date, Alarm, MD and Exact Search (accurate to second) |
| Playback Function | Play; Pause; Stop; Rewind; Fast play; Slow Play; Next File; Previous File; Next Camera; Previous Camera; Full Screen; Repeat; Shuffle; Backup Selection; Digital Zoom |
| Backup Mode | USB Device/Network |
| Third Party Support | Dahua, Arecont Vision, AXIS; Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek, and more |
