Model: V2801SG 1 XPON port(EPON PX20+ and GPON Class B+) 1 x GE, Auto-negotiation RJ45 connectors Detecting Rogue ONU, Hardware Dying Gasp Transmission distance: 20KM Read more
The new VSOL V2801SG Single Port XPON ONU is a versatile and efficient solution designed to cater to the diverse needs of telecom operators. With a focus on providing seamless fiber optic access, VSOL V2801SG is suitable for various applications, including FTTO, FTTD, FTTH, SOHO broadband access, and video surveillance. V2801SG is powered by cutting-edge chip technology, enabling it to support Layer 2 and Layer 3 functions, ensuring carrier-grade FTTH data services. V2801SG ONU comes equipped with a powerful firewall, making it easy to manage and maintain. VSOL V2801SG ONU also ensures Quality of Service for different services, delivering a reliable and efficient broadband experience. Complying with international technical standards such as IEEE802.3ah and ITU-T G.984, this EPON ONU ensures compatibility and interoperability in modern fiber optic networks. Use this for premium quality experience. VSOL V2801SG Single Port XPON ONU comes with 1 year of warranty.
| Specifications | Descriptions |
|---|---|
| Interface and performance | |
| XPON Port | 1 x GPON/EPON port (SC/UPC connector), capable of up to 1.25 Gbps upstream and downstream. |
| Ethernet Port | 1 x 10/100/1000Mbps auto-adaptive Ethernet port (RJ45 connector). |
| Wavelength | 1490nm (Downstream) / 1310nm (Upstream). |
| Transmission Distance | Up to 20 km |
| Management and features | |
| Management Protocols | OMCI, TR-069, SNMP, Web, Telnet, and CLI. |
| Uplink Mode | Supports both Bridging and Routing modes. |
| Security | Firewall with DDOS, ACL, and MAC filtering; supports various authentication methods (Mac/Loid/Mac+Loid). |
| Protection | Detects Rogue ONU and supports Hardware Dying Gasp alarm |
| Environmental and physical | |
| Dimensions | Approximately 82mm × 82mm × 25mm (L×W×H). |
| Weight | Approximately 0.085 kg. |
| Operating Temperature | -30°C to +70°C |
| Operating Humidity | 10% to 90% (Non-condensing) |
| Power | 12V DC (External AC-DC power adaptor); Power consumption ≤ 4W |
