PON Interface:

• 1 XPON port (EPON PX20+ & GPON Class B+)

• SC/UPC connector, single-mode fiber

• TX power: 0 to +4 dBm

• RX sensitivity: -27 dBm

• Transmission distance: up to 20 km

• Wavelengths: TX 1310 nm, RX 1490 nm

WiFi Interface:

• IEEE 802.11b/g/n

• 2T2R MIMO with dual 5dBi external antennas

• Maximum speed: 300 Mbps

• Supports 13 channels and multiple SSIDs

LAN Interface:

• 1 x 10/100/1000 Mbps auto-negotiating RJ45 port

Power Supply:

• DC 12V, 1A external AC-DC adapter

• Power consumption: ≤6W

Physical Dimensions:

• 170 mm × 112 mm × 31 mm (L × W × H)

• Net weight: 0.17 kg

Environmental Conditions:

• Operating temperature: 0°C to +50°C

• Operating humidity: 10% to 90% (non-condensing)
